1. อุปกรณ์เตา
  2. KATO Gas Burner KG-4

KATO Gas Burner KG-4

KATO Gas Burner KG-4(46KW)
  • Gas Burner: KATO Gas Burner KG-4
  • Type: KATO KG-4
  • Capacity:156,958Btu/h = 39,552Kcal/h = 46KW
  • Operation: Two stage
  • Inlet Gas Pressure: 2.8kPa = 28mBar = 11.2"WC
  • Input Voltage: 220VAC 50/60H
  • Burner Control: Azbil R4750A
  • Ignition Tranformer: Azbil S720 A200-GHA
  • Gas Solenoid Valve: CKD
  • Sensor: Flame Rod
  • Brand: KATO BURNER Kato Burner Co.,Ltd.Kato Gas Burner KG-Series Catalog
  • Burner and Burner accessories Made in Japan 100%
  • Kato Gas Burner KG-4 Dimension
  • Kato Gas Burner KG-4 (1)
  • Kato Gas Burner KG-4 (2)
  • Kato Gas Burner KG-4 (3)
  • Kato Gas Burner KG-4 (4)
  • Kato Gas Burner KG-4 (5)
  • Kato Gas Burner KG-4 (6)
  • Kato Gas Burner KG-4 (7)
  • Kato Gas Burner KG-4 (8)
  • Kato Gas Burner KG-4 (9)
  • Kato Gas Burner KG-4 (10)
  • Kato Gas Burner KG-4 (11)
  • Kato Gas Burner KG-4 (12)
  • Kato Gas Burner KG-4 (1)
