PCA1A00-200

PCA1 Shinko | PCA1A00-200
  • Shinko Temperature Controller: PCA1A00-200
  • Model: PCA1A00-200
  • Output Control: Direct current ouput 4-20mA
  • Program Capacity: 16 Patterns,16 Steps,A maximum of 256 programmable steps
  • Type of Input: Thermocuple: K,R,T,J,E,B,S,G,C,N,L,RTD:Pt100,Pt50,J,JPt100,± 10, 0~20, 0~50, ± 200 mVDC, ± 1, 0~5, ± 10 V DC,4-20mA
  • PCA1,Easy status checking using 3-color switching(W96 x H96 x D95mm),USB Cable powered, Quick Setup using a USB Communication Cable
  • Industry-leading premium display,PV Display: 24.0 x 11.0 mm (H x W),SV/MV/TIME Display: 14.0 x 7.0 mm (H x W),Easily legible LCD display with 11-segment characters
  • A Control output: Direct current ouput 4-20mA
  • 0 Power supply voltage: 100 to 240V AC
  • 0 Input: Multi-range
  • 2 Option 1: Serial Communication RS-485 (C5)
  • 0 Option 2: not needed
  • 0 Option 3: not needed
  • Origin: Japan 100%
  • Brand: Shinko
  • Shinko PCA1 Catalog
  • Shinko PCA1 Manaul
  • Shinko PCA1 Software and Usb-Driver
  • Shinko PCA1 ORDERING INFORMATION
